Turning HSR – FRUN
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Wholesaler |
| Download |  View |
Preferred Buyer From
| Location | Worldwide |
FRUN Series self centering steady rest is the latest development from FAR. FRUN hydraulic steady rest is with the following advantage over other standard series hydraulic self centering steady rests.
- Fully sealed body for better protection from coolant and swarf
- Compact in size
- Hydraulic ports on top and side of cylinder
- Inbuilt safety valve
- Feed back for maximum opening
- Port for compressed air.
- Provision for centralized lubrication suitable for Grease or oil lubrication
- Mounting dimensions are similar to FRU series.
- Front body profile for easy chip flow
Specifications
| Model | -- | FRUN1 | FRUN2 | FRUN3 | FRUN3.1 | FRUN3.2 | FRUN4 | FRUN5 | FRUN5.1 |
| Clamping Range (mm) | Minimum | 6 | 8 | 12 | 20 | 50 | 30 | 45 | 85 |
| Maximum | 70 | 101 | 152 | 165 | 200 | 245 | 310 | 350 |
