QF Series (Short Barfeeder)
Price : 3.60 Lac / piece
Get Best Price
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Wholesaler |
| Brand Name | FAR-QF-12/15 - Hydraulic Bar-Feeder |
| Driven Type | Hydraulic |
| Color | White |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Condition
New
Automatic Grade
Semi Automatic
Application
BAR Loading
Certification
ISO 9001:2015
Type
Bar Feeders
Warranty
1yrs
Country of Origin
India
Salient Features : Increase productivity up to 40% Simple automation Absolute unattended machining No Spindle speed restriction 95% up time for turning centers Suitable for all imported and Indian CNC lathes Suitable for Round, Hexagon Options available for Square and other profiles High speed turning End preparation of bar is not required (Deburring is enough) Black bars can be used Compact design Operator friendly control panel.
Specifications
| Model | QF12 S | QF12 P | QF12 H | QF15 S | QF15 P | QF15 H |
| Min. Dia (mm) | 6 | 6 | 6 | 6 | 6 | 6 |
| Max. Dia (mm) | 65 | 65 | 65 | 65 | 65 | 65 |
| Other Diameter | Optional | Optional | Optional | Optional | Optional | Optional |
| Min. Length (mm) | 450 | 450 | 450 | 450 | 450 | 450 |
| Max. Length (mm) | 1200 | 1200 | 1200 | 1500 | 1500 | 1500 |
| Job Feeding | Servo | Pneumatic | Hydraulic | Servo | Pneumatic | Hydraulic |
| Job Loading | Pneumatic | Pneumatic | Hydraulic | Pneumatic | Pneumatic | Hydraulic |
| Magazine width(mm) | 600 | 600 | 600 | 600 | 600 | 600 |
| Reloading of fresh bar | 20 | 25 | 25 | 22 | 28 | 28 |
| Center Height | 950-1300 | 950-1300 | 950-1300 | 950-1300 | 950-1300 | 950-1300 |
| Profile of Bar | Round/Hexagon | Round/Hexagon | Round/Hexagon | Round/Hexagon | Round/Hexagon | Round/Hexagon |
| Other profiles are options | ||||||
